Dry Medium Intensity Magnetic Separator (DMIMS)

This DMIMS is a Salient Pole Rare Earth Drum Separtor.

Lab Model
15 inch diameter by 13 ¼ inch drum width with 9 ½ inch magnet width.
11-gauge stainless steel drum shell with cast aluminum end flanges and flange cartridge bearings.
Magnetic element will be constructed using high-energy Neodymium- Boron-Iron rare earth magnets. The element will be a "Salient Pole" configuration spanning an approximate 110 degree arc.
Wide range splitter for segregating the non-magnetic from the magnetic fraction.
1 H.P. variable speed drive. Drum speed variable to 300 fpm. Electrical input is 230 V.A.C., 3 phase, 60 cycle.
Chain and sprocket drive with chain guard.
Model 36C electromagnetic feeder with 7 inch wide by 17 inch long stainless steel feeder tray. 1 1/4 cubic foot hopper with adjustable slide gate.
Feed rate is infinitely adjustable with feeder control. Electrical input is 230 V.A.C., single phase, 60 cycle.
The unit will be shipped completely assembled and wired ready for installation and operation.

Multiple voltage options available upon request.

Product Table

Item Name	Part Number	Description
DMIMS SPRE 13.25 Drum	549	Dry Medium Intensity Magnetic Separator Lab Model 15-Inch Diameter By 13.25 Drum width Salient Pole Rare Earth Drum Separator.

Item Name

Part Number

Description

DMIMS SPRE 13.25 Drum

549

Dry Medium Intensity Magnetic Separator

Lab Model 15-Inch Diameter By 13.25 Drum width Salient Pole Rare Earth Drum Separator.
